Intergral six-sided acoustic enclosure - Compact Vee Cylinder design.
High Power Density - Higher output for a lower displacement.
Least impacted by the ambient conditions, humidity and altitude.
Fully Electronic Engine - highest transient response (60%) and lowest fuel consumption.
Confirm to G2 governing class of steady state and transient response and frequency fluctuation limit.
| Prime Power Output |
Engine Manufacturer |
Engine Model |
Gross Engine Power |
Engine Cooling System |
No. of Cylinder and Position | Displacement | Aspiration |
|---|---|---|---|---|---|---|---|
| 450 kVA/ 360 kW | Generac | G25.8L | 462 bKW | Liquid Cooled | 12- Vee | 25.8 Litres | Turbocharged, air to air cooled |
| Bore x Stroke | Recommended Fuel |
Combustion System |
Compression Ratio |
Total Lubricating Capacity |
Total Coolant Capacity |
Fuel Consumption (m3/hr) | |
| 132 x 160 mm | Pipe Natural Gas | Spark Ignition | 10:00:01 | 90 Litres | 77.6 Litres | 100% Load : 118.4 75 % Load : 94.8 50% Load : 71.1 |
|
| Alternator Rated Power |
Rated Voltage (L-L) |
Frequency | Rated Speed |
Rated Current |
Power Factor |
Poles | Phase |
| 500 kVA / 400 kW | 415 V | 50 Hz | 1500 rpm | 695.6 amp | 0.8 (lagging) | 4 | 3 |
| Insulation Class | Temperature Rise Limit |
Protection | Voltage Regulation |
Over Load Capability |
Excitation System |
||
| Class H | Class H | IP 23 | ± 1% | 10% for 1 hour in every 12 hours operation |
Brushless |
| Prime Power Output | 450 kVA / 360 kW |
|---|---|
| Engine Manufacturer | Generac |
| Engine Model | G25.8L |
| Gross Engine Power | 462 bKW |
| Engine Cooling System | Liquid Cooled |
| No.of Cylinder and Position | 12 - Vee |
| Displacement | 25.8 Litres |
| Aspiration | Turbocharged, air to air cooled |
| Bore x Stroke | 132 x 160 mm |
| Recommended Fuel | Pipe Natural Gas |
| Combustion System | Spark ignition |
| Compression Ratio | 10:00:0.1 |
| Total Lubricating Capacity | 90 Litres |
| Total Coolant Capacity | 77.6 Litres |
| Fuel Consumption (m3/hr) | 100% Load : 118.4 75 % Load : 94.8 50% Load : 71.1 |
| Alternator Rated Power | 500 kVA / 400 kW |
| Rated Voltage (L-L) | 415 V |
| Frequency | 50 Hz |
| Rated Speed | 1500 rpm |
| Rated Current | 695.6 amp |
| Power Factor | 0.8 (lagging) |
| Poles | 4 |
| Phase | 3 |
| Insulation Class | Class H |
| Temperature Rise Limit | Class H |
| Protection | IP 23 |
| Voltage Regulation | ± 1% |
| Over Load Capability | 10% for 1 hour in every 12 hours operation |
| Excitation System | Brushless |
