Most compact genset in this range. Smallest in size with latest emission and noise complaince.
Proven across the globe with different environment condition like cold and extreme hot condition.
Fully Electronic Engine- unparallel transient response (55%) and lowest fuel consumption in this range.
Complies NFPA-110 norms of starting a taking entire load in less than 10 seconds*(*conditions applied).
Conform to G2 governing class of steady state and transient response and frequency fluctuation limit.
| Standby Power Output |
Engine Manufacturer |
Engine Model |
Gross Engine Power |
Engine Cooling System |
ENo.of Cylinder and Position | Displacement | Aspiration |
|---|---|---|---|---|---|---|---|
| 315 kVA/ 252 kW | Generac | G14.2L | 276 bkW | Liquid Cooled | 6, In-line | 14.2 Litres | Turbocharged, air to air cooled |
| Bore x Stroke | Recommended Fuel |
Combustion System |
Compression Ratio |
Total Lubricating Capacity |
Total Coolant Capacity |
Fuel Consumption (m3/hr) | |
| 135 x 165 mm | Pipe Natural Gas | Spark Ignition | 9.5:1 | 34.3 Litres | 54.9 Litres | 100% Load : 77.7 75 % Load : 60.6 50% Load : 42.1 |
|
| Alternator Rated Power |
Rated Voltage (L-L) |
Frequency | Rated Speed |
Rated Current |
Power Factor |
Poles | Phase |
| 320 kVA / 256 kW | 415 V | 50 Hz | 1500 rpm | 445.2 amp | 0.8 (lagging) | 4 | 3 |
| Insulation Class | Temperature Rise Limit |
Protection | Voltage Regulation |
Over Load Capability |
Excitation System |
||
| Class H | Class H | IP 23 | ± 1% | Not available | Brushless |
| Standby Power Output | 315 kVA/ 252 kW |
|---|---|
| Engine Manufacturer | Generac |
| Engine Model | G14.2L |
| Gross Engine Power | 276 bkW |
| Engine Cooling System | Liquid Cooled |
| No.of Cylinder and Position | 6, In-line |
| Displacement | 14.2 Litres |
| Aspiration | Turbocharged, air to air cooled |
| Bore x Stroke | 135 x 165 mm |
| Recommended Fuel | Pipe Natural Gas |
| Combustion System | Spark ignition |
| Compression Ratio | 9.5:1 |
| Total Lubricating Capacity | 34.3 Litres |
| Total Coolant Capacity | 54.9 Litres |
| Fuel Consumption (m3/hr) | 100% Load : 77.7 75 % Load : 60.6 50% Load : 42.1 |
| Alternator Rated Power | 320 kVA / 256 kW |
| Rated Voltage (L-L) | 415 V |
| Frequency | 50 Hz |
| Rated Speed | 1500 rpm |
| Rated Current | 445.2 amp |
| Power Factor | 0.8 (lagging) |
| Poles | 4 |
| Phase | 3 |
| Insulation Class | Class H |
| Temperature Rise Limit | Class H |
| Protection | IP 23 |
| Voltage Regulation | ± 1% |
| Over Load Capability | Not available |
| Excitation System | Brushless |
