Deliver steady performance at various climatic and load conditions.
Electronic Controller for full time engine control, complete engine management, diagonistic and communication capability.
Designed for longer trouble free operation with minimum intervention.
Conform to G2 governing class of steady state and transient response and frequency fluctuation limit.
Lowest owning & Operating cost in this category.
| Prime Power Output |
Engine Manufacturer |
Engine Model |
Gross Engine Power |
Engine Cooling System |
No.of Cylinder and Position | Displacement | Aspiration |
|---|---|---|---|---|---|---|---|
| 250 kVA/ 200 kW | Generac | G14.2L | 276 bkW | Liquid Cooled | 6, In-line | 14.2 Litres | Turbocharged, air to air cooled |
| Bore x Stroke | Recommended Fuel |
Combustion System |
Compression Ratio |
Total Lubricating Capacity |
Total Coolant Capacity |
Fuel Consumption (m3/hr) | |
| 135 x 165 mm | Pipe Natural Gas | Spark ignition | 9.5:1 | 34.3 Litres | 54.9 Litres | 100% Load : 63.9 75 % Load : 48.82 50% Load : 36.1 |
|
| Alternator Rated Power |
Rated Voltage (L-L) |
Frequency | Rated Speed |
Rated Current |
Power Factor |
Poles | Phase |
| 320 kVA / 256 kW | 415 V | 50 Hz | 1500 rpm | 417.3 amp | 0.8 (lagging) | 4 | 3 |
| Insulation Class | Temperature Rise Limit |
Protection | Voltage Regulation |
Over Load Capability |
Excitation System |
||
| Class H | Class H | IP 23 | ± 1% | 10% for 1 hour in every 12 hours operation |
Brushless |
| Prime Power Output | 250 kVA/ 200 kW |
|---|---|
| Engine Manufacturer | Generac |
| Engine Model | G14.2L |
| Gross Engine Power | 276 bkW |
| Engine Cooling System | Liquid Cooled |
| No.of Cylinder and Position | 6, In-line |
| Displacement | 14.2 Litres |
| Aspiration | Turbocharged, air to air cooled |
| Bore x Stroke | 135 x 165 mm |
| Recommended Fuel | Pipe Natural Gas |
| Combustion System | Spark ignition |
| Compression Ratio | 9.5:1 |
| Total Lubricating Capacity | 34.3 Litres |
| Total Coolant Capacity | 54.9 Litres |
| Fuel Consumption (m3/hr) | 100% Load : 63.9 75 % Load : 48.82 50% Load : 36.1 |
| Alternator Rated Power | 320 kVA / 256 kW |
| Rated Voltage (L-L) | 415 V |
| Frequency | 50 Hz |
| Rated Speed | 1500 rpm |
| Rated Current | 417.3 amp |
| Power Factor | 0.8 (lagging) |
| Poles | 4 |
| Phase | 3 |
| Insulation Class | Class H |
| Temperature Rise Limit | Class H |
| Protection | IP 23 |
| Voltage Regulation | ± 1% |
| Over Load Capability | 10% for 1 hour in every 12 hours operation |
| Excitation System | Brushless |
